SC - FC , FC - ST Hybrid Plastic Fiber Optic Cable Adapter Multimode For Testing Instruments

China SC - FC , FC - ST Hybrid Plastic Fiber Optic Cable Adapter Multimode For Testing Instruments supplier
SC - FC , FC - ST Hybrid Plastic Fiber Optic Cable Adapter Multimode For Testing Instruments supplier SC - FC , FC - ST Hybrid Plastic Fiber Optic Cable Adapter Multimode For Testing Instruments supplier

Large Image :  SC - FC , FC - ST Hybrid Plastic Fiber Optic Cable Adapter Multimode For Testing Instruments

Product Details:

Place of Origin: China
Brand Name: FOCABLE
Certification: RoHS Compliant, ISO Certificate
Model Number: SC-FC, SC-ST, FC-ST Fiber Optic Adapter

Payment & Shipping Terms:

Minimum Order Quantity: 100PCS
Packaging Details: 50PCS/Blister Box
Supply Ability: 90000PCS/Month
Contact Now
Detailed Product Description
Sleeve Material: Bronze Sleeve, Zirconia Ceramic Sleeve Adapter: FC, SC, ST, LC, MTRJ, MPO, E2000
Cores: Simplex, Duplex, Quad Material: Metal, Plastic
Cap Color: White, Red Mode: Singlemode, Multimode

SC - FC , FC - ST Hybrid Plastic Fiber Optic Cable Adapter Multimode For Testing Instruments

Fiber optic adapter LC/FC/SC/ST hybrid provides the connection between the fiber optic patch cord or pigtails. Fiber optic adapters (also called couplers) are designed to connect two fiber optic cables together. They come in versions to connect single fibers together (simplex), two fibers together (duplex), or sometimes four fibers together (quad).



Fiber Optic Adapters are an important component in a fiber optic network; they are used in a fiber optic patch panel or any other outlet to mate two connectors. Fiber Optic adaptors are available for all standard connector types in both single mode and multimode including Simplex and duplex versions.

Our fiber optic adapters are made with high precision machines which ensure precise alignment for the connectors when they are plugged in. fiber Optic Adaptors are color coded allowing easy identification of the adaptor type.



Fiber Optic Adapter Specifications

Operating Temperature -40 to +75º C
Storage Temperature: -40 to +85º C
Temperature Cycling (61300-2-18) -40 to +75º C, 40 cycles=0.2dB change
High temperature (61300-2-18) 70˚c for 96Hrs, <0.4dB change
Damp Heat (61300-2-19) 40º C at 93%RH for 96 Hrs, <0.4dB change
Vibration-Mated Pair (61300-2-1) 10-55Hz, 1.5mm P to P <0.2dB change
Mating Durability (61300-2-2) 500 Mating Cycles, clean every 25, <0.2dB chang



Fiber Optic Adapter Features
Good compatibility
High precision of dimensions

Good reliability & stability

Zicornia Ceramic Sleeve

PC and APC fiber stub port

Single mode and Multimode

Various Styles and Colors support


Fiber Optic Adapter Applications

CATV Networks
Telecommunication Networks
Local Area Networks(LANS) and Wide Area Networks(WANS)
FTTH and FTTx
Active Device Termination
Testing Instruments



Ordering Information

Interface

Adapter Type

Color

Fiber Type

Cores

Sleeve

P-PC

FC-FC

B-Blue

SM

Simplex

Zirconia

A-APC

SC-SC

B-Beige

MM 50/125um

Duplex

Bronze



LC-LC

G-Green

MM 62.5/125um

4cores





ST-ST

X-Customized

MM OM3







MU-MU











MTRJ-MTRJ











E2000-E2000











Hyrbid











SC - FC , FC - ST Hybrid Plastic Fiber Optic Cable Adapter Multimode For Testing Instruments

Fiber Optic Adapter, Optical Fiber Adapter, Fiber Optic Coupler
