• Ribbon Fan Out Fiber Plc Splitter 1 × 32 For Optical Signal Distribution
Ribbon Fan Out Fiber Plc Splitter 1 × 32 For Optical Signal Distribution

Ribbon Fan Out Fiber Plc Splitter 1 × 32 For Optical Signal Distribution

Product Details:

Place of Origin: China
Brand Name: FOCABLE
Certification: ISO Certification and RoHS Compliant
Model Number: 1 × 32 PLC Splitter Ribbon Fan Out Type

Payment & Shipping Terms:

Minimum Order Quantity: 10PCS
Packaging Details: 1pcs/blister box
Payment Terms: Western Union, T/T
Supply Ability: 90000PCS/MONTH
Get Best Price Contact Now

Detail Information

Fiber Type: G.652D, G.657A Cable Type: PVC Or LSZH Jacket
Fiber Tube: 0.9mm Tube, 2.0mm Tube, 3.0mm Tube Connector Type: SC/UPC, SC/APC, FC/UPC, FC/APC, LC/UPC, LC/APC
Port: 1*2, 1*4, 1*8, 1*16, 1*32, 1*64, 2*4, 2*8, 2*16, 2*32, 2*64 Operating Wavelength: 1260-1650nm
High Light:

passive optical splitter

,

fiber optic splitters

Product Description

Ribbon Fan Out Fiber Plc Splitter 1 × 32 For Optical Signal Distribution
This optical splitter use Planer Light wave Circuit (PLC) technology for split ratio 2, 4, 8,16, 32 and 64. Optical splitter micro tube type refers to the port 0.9 mm slip-on fiber multi channel direct output with a compact design and easy to use.


Planar lightwave circuit splitter (PLC Splitter) is a kind of integrated waveguide optical power distribution device based on quartz substrate. It has the advantages of small volume, wide bandwidth, high reliability, excellent uniformity. Optical fiber splitter is especially suitable for passive optical networks (EPON, BPON, GPON) which is connected with the terminal equipment and realize the optical power distribution.

FOC COMMUNICATION CO., LTD provides 1*N and 2*N fiber optic splitters. And these PLC splitters can be made as per customer request.



Features

Low Insertion loss
Low PDL
High Return Loss
Uniform Power Splitting
Compact Design
Wide Operating Wavelength
Wide Operating Temperature
Excellent Environmental and Mechanical Stability
Qualified Under Telcordia GR-1221 and GR-1209



Applications

FTTX (FTTP, FTTH, FTTN, FTTC)
Passive Optical Networks (PON)
Local Area Networks (LAN)
CATV Systems
Optical Signal Distribution
Test Equipments


Optical Specifications

Parameter

Unit

Specification (P Grade)

Channel Number



1X2

1X4

1X8

1X16

1X32

1X64

Operation Wavelength

nm

1260~1650

Insertion Loss (Max.)

dB

4.3

7.4

10.7

13.9

17.2

21.5

Uniformity (Max.)

dB

0.5

0.8

1.0

1.4

1.6

2.0

Polarization Dependent Loss

dB

0.2

0.3

0.3

0.3

0.3

0.5

Return Loss

dB

≥50

Directivity

dB

≥50

Operating Temperature

-40~+85

Storage Temperature

-40~+85



Parameter

Unit

Specification (P Grade)

Channel Number



2X2

2X4

2X8

2X16

2X32

2X64

Operation Wavelength

nm

1260~1650

Insertion Loss (Max.)

dB

4.3

7.6

11.0

14.8

17.9

21.5

Uniformity (Max.)

dB

0.8

1.0

1.2

1.5

1.8

2.0

Polarization Dependent Loss

dB

0.2

0.3

0.3

0.3

0.3

0.5

Return Loss

dB

≥50

Directivity

dB

≥50

Operating Temperature

-40~+85

Storage Temperature

-40~+85

Note: All the data above does not include connectors.

Ordering Information

PLC















Port

Fiber Type

Input

Output

Pigtail Length

Connector





PLC

0102=1x2
0104=1x4
0108=1x8
0116=1x16
0132=1x32
0164=1x64
0204=2x4
0208=2x8
0216=2x16
0232=2x32
0264=2x64

1=G652D, 2=G657A

L=900µm Loose tube, S=2.0mm, R=3.0mm, 0=Adapter

L=900µm Loose tube, S=2.0mm, R=3.0mm, 0=Adapter

05-20=0.5--2.0m, 0=Adapter, X=Others

FU=FC/UPC, FA=FC/APC, SU=SC/UPC, SA=SC/APC, ST=ST/UPC, LU=LC/UPC, LA=LC/APC, 00=None, X=Others


Ribbon Fan Out Fiber Plc Splitter 1 × 32 For Optical Signal Distribution 0
Ribbon Fan Out Fiber Plc Splitter 1 × 32 For Optical Signal Distribution 1



Ribbon Fan Out Fiber Plc Splitter 1 × 32 For Optical Signal Distribution 2

We can produce many serials of PLC splitters including
1X2, 1X4, 1X8, 1X16, 1X32, 1X64, 2X4, 2X8, 2X16, 2X32, 2X64 with following package
Bare Fiber PLC Splitter
Blockless Fiber Optic PLC Splitter
ABS Module Fiber Optical PLC Splitter
LGX Box Optical PLC Splitter

Cassette Box PLC Splitter

Pallet Type PLC Splitter
Rack Mount Optical Fiber PLC Splitter for PON application
Wall Mount PLC Splitters



Ribbon Fan Out Fiber Plc Splitter 1 × 32 For Optical Signal Distribution 3        Ribbon Fan Out Fiber Plc Splitter 1 × 32 For Optical Signal Distribution 4



Advantages

1. Guaranteed high quality products

2. Fast delivery speed

3. Safety Shipping

4. Quick Response within 24hours



We deliver products and we deliver efficient service for you!
