SC OM1 900um 1 Meters LSZH fibre optic pigtails With Precision Ferrule For FTTX

China SC OM1 900um 1 Meters LSZH fibre optic pigtails With Precision Ferrule For FTTX supplier

Large Image :  SC OM1 900um 1 Meters LSZH fibre optic pigtails With Precision Ferrule For FTTX

Product Details:

Place of Origin: China
Brand Name: FOCABLE
Certification: ISO, RoHS Compliant
Model Number: SC Fiber Optic Pigtail MM

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Packaging Details: 1PCS/Blister Box
Contact Now
Detailed Product Description
Cable: LSZH Core: Simplex
Fiber: SM Inner Diameter: 0.9mm
Connector: SC Length: 1.5M

SC OM1 900um 1 Meters LSZH fibre optic pigtails With Precision Ferrule For FTTX

SC/UPC pigtail, suitable for ODF and patch panel. It can be reinstalled in ODF and can save the space.



Fiber Optic Pigtail is a piece of cable assembled with connectors only in one side. And the other side has no connectors. Then the other side is usually spliced with other fiber optic cable. It is preinstalled in the fiber optic terminal box, ODF, fiber optic joint closure to connect the equipment. There are single mode and multimode pigtails, the wavelength of single mode pigtail is 1310/1550nm and the color is yellow in common. If multimode fiber optic pigtail, the color is orange. We also provide non-jacketed fiber optic pigtail and jacketed pigtails.



Breakout optical fiber pigtail, distribution pigtail and ribbon fan out pigtails are also available.

Customer label and OEM design can be produced as per request.



Material

Cores: simplex, multi core pigtails (6pack, 8pack, 12pack, 24pack, 48pack)

Cable Jacket: PVC, LSZH, OFNR, OFNP

Cable outer diameter: 0.9mm, 2.0mm, 3.0mm

Fiber Type: SM (9/125um), OM1(62.5/125um), OM2(50/125um), OM3, OM4

Connector Type: FC, SC, ST, LC, MU, MTRJ, MPO, E2000, SMA, FDDI, D4, DIN

End face type: UPC, APC



Our Adavantage
More than 10 years experience
Over 200 professional workers
Export more than 30 countries
Certified with ISO9001:2008,ROHS
Free samples can be supplied for your test



Features

Low insertion loss

High return loss

Excellent repeatability

Compact and anti-pull design
Precision fiber optic ferrule
UPC, PC or APC polished connectors



Applications

Local area networks, wide area networks

Optical Switch interface connections

Telecommunication Networks

Fiber to the home



Specifications

Parameter Specifications
Single mode fiber pigtail Multimode fiber pigtail
Testing wavelength 1310nm, 1550nm 850nm, 1300nm
Insertion loss Typical≤0.2dB, max≤0.3dB Typical≤0.2dB, max≤0.3dB
Return loss UPC≥50dB, APC≥60dB, ≥35dB,
Repeatability ≤0.1dB
Exchangeability ≤0.2dB
Durability 1000 Mating, typical≤0.2dB
Operating Temperature -20℃ to +70℃
Storage Temperature -40℃ to +85℃



SC OM1 900um 1 Meters LSZH fibre optic pigtails With Precision Ferrule For FTTX
