0.9mm LSZH Jacket 1.5M Multimode Pigtail LC Connector For CATV and WAN

China 0.9mm LSZH Jacket 1.5M Multimode Pigtail LC Connector For CATV and WAN supplier
0.9mm LSZH Jacket 1.5M Multimode Pigtail LC Connector For CATV and WAN supplier 0.9mm LSZH Jacket 1.5M Multimode Pigtail LC Connector For CATV and WAN supplier

Large Image :  0.9mm LSZH Jacket 1.5M Multimode Pigtail LC Connector For CATV and WAN

Product Details:

Place of Origin: China
Brand Name: FOCABLE
Certification: ISO, RoHS Compliant
Model Number: LC OM3 Fiber Optic Pigtail

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Packaging Details: 1PCS/Blister Box
Contact Now
Detailed Product Description
Cable: LSZH Cores: 12core
Fiber: OM2 Outer Diameter: 0.9mm
Connector: LC Length: 1M, 2M, 3M, 5M Or As Per Customer Request

0.9mm LSZH Jacket 1.5M Multimode Pigtail LC Connector For CATV and WAN

Fiber optic pigtail is the product having standard fiber optic connector terminated at one end and leaving open at the other end. According to connector type, fiber optic pigtails can be divided in SC fiber optic pigtail, LC fiber optic pigtail, FC, ST, MU, E2000, SMA, MTRJ, MPO etc such fiber optic pigtails. According to the cable type, fiber optic pigtails can be divided in 0.9mm buffered pigtail with 12 colors,12F fan-out fiber optic pigtail, ribbon fiber optic pigtail, water-proof pigtail, etc.

We supply the LC UPC fiber optic cables and connectors, adapters, attenuators. LC/UPC is used in multi media, CATV, and premise installation.

We supply LC/UPC Multimode 50um 10Gb OM3 Fiber Optic Pigtails with competitive price. We supply quality LC/UPC Multimode Fiber Optic Pigtails are Individual Pigtails 1 meters long with 900um outer jacket. Ideal for fusion splicing.
We also offer custom-made specification pigtails, please contact us for details.

Features
1. Meets ISO9001, ROHS and Bell core GR 326-core standards;
2. Customized specifications are welcomed.
3. Superior qualified standard PC, APC, UPC, SPC polishing;
4. 100% optic test: Insertion Loss: ≤0.3 (PC); ≤0.2 (APC); ≤0.2 (UPC); ≤0.3 (SPC);
5. 100% optic test: Return Loss: ≥45 (PC); ≥60 (APC); ≥55 (UPC); ≥50 (SPC);
6. FC, SC, LC, MU, ST, MT-RJ, etc connector
7. Single mode (9/125) or multi mode (50/125 or 62.5/125) fiber available;
8. φ0.9mm, φ2.0mm, φ3.0mm cable optional;
9. Simplex and duplex connector available;
10. Good exchange ability and good durability;
11. Available in fiber bunch, ribbon fan-out, pigtail available;

Applications
1. Local area networks (LAN);
2. Wide area networks (WAN);
3. CATV, metro test equipment;
4.Telecommunication networks;
5. Data processing networks;
6. Premise installations;
7. Video and military active device termination.



Ordering Information

Fiber mode Singlemode (9/125um G652D/G657/G655) or Multimode (62.5/125um OM1,OM2,OM3,OM4)
Fiber count Simplex,Duplex or 4, 6, 8, 12, 24, 48 cores are available
Cable diameter 0.9mm/1.2mm/1.6mm/1.8mm/2.0mm/3.0mm etc.
Cable jacket PVC,LSZH,OFNR,OFNP
Cable color SM-Yellow, OM1/OM2-Orange, OM3-Aqua green, OM4-Purple or OEM color
Cable length(M) Customized
Connector type LC, SC, FC, ST, MU, MTRJ, MPO, SMA, D4 and others
Ferrule Ceramic/Zirconia ferrule, made in China or Japan
Polish/Endface PC, UPC, APC
Housing/boot color Standard(Blue/Beige/Green) or OEM color
Packing Multi-piece or one piece type available,Normally polybag+carton box, can be customized
