1*8 Fiber PLC Splitter LGX Type Rack Mount With SC / UPC Connector Low Insertion
Product Details:
| Place of Origin: | China |
| Brand Name: | FOCABLE |
| Certification: | ISO Certification and RoHS Compliant |
| Model Number: | 1*8 LGX Type PLC Splitter |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10PCS |
|---|---|
| Packaging Details: | 1pcs/carton box |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 90000PCS/MONTH |
|
Detail Information |
|||
| Port: | 1*2, 1*4, 1*8 | Connector Type: | SC/UPC,SC/APC,FC/UPC,FC/APC,LC/UPC |
|---|---|---|---|
| Cable Material: | PVC, LSZH | Fiber Type: | G.652D, G.657A |
| High Light: | plc optical splitter,passive optical splitter |
||
Product Description
1*8 Fiber PLC Splitter LGX Type Rack Mount With SC / UPC Connector Low Insertion
LGX splitter is design in a LGX module which is used for LGX chassis application. It is also terminated with adapters and according to different requirements, LGX modules can be inserted into the chassis. In addition, LGX splitter can also installed in rack mount chassis.
As one of the most important components of PON (Passive Optical Network) systems, the market of PLC (Planar Lightwave Circuit) splitters has grown rapidly. If you are the first time to buy PLC splitters, you might be curious about the package type of it. Actually, it is not as complex as you think.
FOC COMMUNICATION CO., LTD provides 1*N and 2*N fiber optic splitters. And these PLC splitters can be made as per customer request.
At present, there are six major package type of PLC splitters according to different applications, suce as, bare fiber splitter, module splitter, rack-mount splitter, fan-out & blockless splitter, Tray splitter and LGX splitter. Of course, these are the basic types and there are upgrade version on their foundation offered by different vendors. For example, the following shows us the PLC splitters with different package types.
- Bare fiber optical splitter
- ABS splitters
- Blockless fiber splitter
- Fan out splitter
- Tray splitter
- Rack-mount splitter
- LGX splitters
- PLC splitter in mini plug-in type
Features
Low Insertion loss
Low Polarization Dependent Loss
High Return Loss
Uniform Power Splitting
Compact Design
Wide Operating Wavelength
Wide Operating Temperature
Excellent Environmental & Mechanical Stability
Qualified Under Telcordia GR-1221 and GR-1209
Applications
FTTX (FTTP, FTTH, FTTN, FTTC)
Passive Optical Networks (PON)
Local Area Networks (LAN)
CATV Systems
Optical Signal Distribution
Test Equipments
Optical Specifications
|
Parameter |
Unit |
Specification (P Grade) |
|||||
|
Channel Number |
|
1X2 |
1X4 |
1X8 |
1X16 |
1X32 |
1X64 |
|
Operation Wavelength |
nm |
1260～1650 |
|||||
|
Insertion Loss (Max.) |
dB |
4.3 |
7.4 |
10.7 |
13.9 |
17.2 |
21.5 |
|
Uniformity (Max.) |
dB |
0.5 |
0.8 |
1.0 |
1.4 |
1.6 |
2.0 |
|
Polarization Dependent Loss |
dB |
0.2 |
0.3 |
0.3 |
0.3 |
0.3 |
0.5 |
|
Return Loss |
dB |
≥50 |
|||||
|
Directivity |
dB |
≥50 |
|||||
|
Operating Temperature |
℃ |
-40～+85 |
|||||
|
Storage Temperature |
℃ |
-40～+85 |
|||||
|
Parameter |
Unit |
Specification (P Grade) |
|||||
|
Channel Number |
|
2X2 |
2X4 |
2X8 |
2X16 |
2X32 |
2X64 |
|
Operation Wavelength |
nm |
1260～1650 |
|||||
|
Insertion Loss (Max.) |
dB |
4.3 |
7.6 |
11.0 |
14.8 |
17.9 |
21.5 |
|
Uniformity (Max.) |
dB |
0.8 |
1.0 |
1.2 |
1.5 |
1.8 |
2.0 |
|
Polarization Dependent Loss |
dB |
0.2 |
0.3 |
0.3 |
0.3 |
0.3 |
0.5 |
|
Return Loss |
dB |
≥50 |
|||||
|
Directivity |
dB |
≥50 |
|||||
|
Operating Temperature |
℃ |
-40～+85 |
|||||
|
Storage Temperature |
℃ |
-40～+85 |
|||||
Note: All the data above does not include connectors.
Ordering Information
|
PLC |
|
|
|
|
|
|
|
|
Port |
Fiber Type |
Input |
Output |
Pigtail Length |
Connector |
|
|
0102=1x2 |
1=G652D, 2=G657A |
L=900µm Loose tube, S=2.0mm, R=3.0mm, 0=Adapter |
L=900µm Loose tube, S=2.0mm, R=3.0mm, 0=Adapter |
05-20=0.5--2.0m, 0=Adapter, X=Others |
FU=FC/UPC, FA=FC/APC, SU=SC/UPC, SA=SC/APC, ST=ST/UPC, LU=LC/UPC, LA=LC/APC, 00=None, X=Others |
