PVC SM Fibre Optic Patch Cables SC / APC Duplex Low Insertion Loss
Product Details:
| Place of Origin: | China |
| Brand Name: | FOCABLE |
| Certification: | RoHS Compliant, SGS Certificate, ISO Certificate |
| Model Number: | SC/APC SM Duplex Fiber Patch Cord |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10PCS |
|---|---|
| Packaging Details: | 1PCS/PE Bag |
| Delivery Time: | 3-5days |
|
Detail Information |
|||
| Fiber Type: | SM | Cable Material: | PVC |
|---|---|---|---|
| Cable Diameter: | 3.0mm | Connector: | SC/APC, LC/UPC |
| Cores: | Duplex | Length: | 5M, 10M Or As Per Customer Request |
| High Light: | multimode fiber optic cable,fiber optic jumper |
||
Product Description
PVC SM Fibre Optic Patch Cables SC / APC Duplex Low Insertion Loss
If single mode, G.652D, G.655, G.657 fiber can be chosen.
If multimode, OM1, OM2, OM3, OM4 fiber can be chosen.
For cores, there are simplex, duplex, 4core, 6core, 8core, 12core, 24core
For cable jacket, PVC, LSZH, PU, OFNP, OFNR
Single mode fiber optic patch cords can be used to cross connect patch panels. As connector styles evolved hybrid cables become more popular.
We are leading manufacturer of fiber optic patch cord in China. We produce single mode fiber optic patch cable, multimode patch cord, simplex fiber patch cord, duplex optical fiber patch cord and so on. FC, LC, SC, ST, MU, E2000, MTRJ, MPO type patch cords are all available upon customer's request.
Why do you choose FOCABLE?
1.We are manufacture, factory, so we have the ability of mass production and we can meet the customer urgent shipping request.
2. OEM and ODM order are optional.
We provide Patch Cords, FC/LC/SC/ST connectors, PC/UPC/APC, Simplex/duplex, OM3 0.9/2.0/3.0mm customized lengths according to your requirements, and customize packaging available.
3. High quality products. All parts sold by FOC COMMUNICATION CO., LTD meet all of the manufactures specifications and carry 12 months warranty. Some customized products could carry up to three years warranty. We test each piece of fiber optic products before shipping to make sure the patch cords, PLC Splitters can work in your system without any problems.
4.Good packing. We pack the patch cords in PE bag or blister per piece and give the customers satisfaction on the packing. We can also pack the goods upon customer's request.
5. Fast delivery. Shipping goods on time and guarantee to meet the needs on delivery time.
6. To achieve customers' satisfaction, we accept sample order, even one Piece.
7. Quick Response within 24hours. Any problem, please contact us immediately and we will give you reply immediately.
Features
Low insertion loss, high return loss
High dense connection, easy for operation
High credibility and stability
Good in repeatability and exchangeability
Applications
Fiber Optic Telecommunication
Testing Instruments
Local Area Networks(LANS)
Data Processing Networks
Premise Installations
Active Device Termination
FTTX
Specifications
|
Type |
Single Mode (typical) |
Single Mode (maximum) |
Multimode(maximum) |
|
Insertion Loss |
≤0.15dB |
≤0.3dB |
≤0.3dB |
|
Return Loss |
≥55dB |
≥50dB |
≥25dB |
|
Operating Temperature |
-40℃ to +80℃ |
-40℃ to +80℃ |
-40℃ to +80℃ |
Technical Test Data
|
Test item |
Test condition |
|
Wet-resistance |
Temperature:85ºC/relative humidity 85％/14days/insertion loss≤0.1dB |
|
Temperature change |
Temperature: -40ºC~+75ºC/relative humidity 10％-80％ /42 repetitions/14days/ insertion loss≤0.1dB |
|
Water resistance |
Temperature: 43ºC, /PH5.5,/ 7days /insertion loss≤0.1dB |
|
Vibrancy |
Swing 1.52mm/frequency 10Hz～55Hz,/ X,Y,Z three directions:2 hours /insertion loss≤0.1dB |
|
Load bend |
0.454kg load/100circles insertion loss≤0.1dB |
|
Load torsion |
0.454kg load/10 circles insertion loss ≤0.1dB |
|
Tensility resistance |
0.23kg pull (nakedness fiber),1.0kg(with shell ) insertion≤0.1dB |
|
Strike |
High 1.8m,three directions ,8 in each direction/insertion loss≤0.1dB |
|
Reference standard |
Bellcore TA-NWT-001209 insertion loss≤0.1dB |
Rema Remark: The load bend and load torsion not suitable for 0.9mm patch cord or pigtail.
Order Ordering information
|
Interface |
Connector |
Length |
OD |
Color of jacket |
Jacket |
Fiber Type |
Cores |
|
P-PC |
FC-FC |
1M |
0.9mm |
B-Black |
P-PVC |
SM |
Simplex |
|
U-UPC |
SC-SC |
3M |
1.6mm |
Y-Yellow |
L-LSZH |
MM 50/125um |
Duplex |
|
A-APC |
LC-LC |
5M |
1.8mm |
W-White |
OFNR |
MM 62.5/125um |
4cores |
|
|
ST-ST |
10M |
2.0mm |
Customized |
OFNP |
MM OM3 |
6cores |
|
|
MU-MU |
Customized |
3.0mm |
|
Customized |
MM OM4 |
8cores |
|
|
MTRJ-MTRJ |
|
Customized |
|
|
|
12cores |
|
|
E2000-E2000 |
|
|
|
|
|
24cores |
|
|
DIN |
|
|
|
|
|
Customized |
|
|
Customized |
|
|
|
|
|
|
