• Fiber Planar Lightwave Circuit Fiber Optic Splitter ABS Module Low PDL 1 × 32
Fiber Planar Lightwave Circuit Fiber Optic Splitter ABS Module Low PDL 1 × 32

Fiber Planar Lightwave Circuit Fiber Optic Splitter ABS Module Low PDL 1 × 32

Product Details:

Place of Origin: China
Brand Name: FOCABLE
Certification: ISO Certification and RoHS Compliant
Model Number: 1 × 32 PLC Splitter Module

Payment & Shipping Terms:

Minimum Order Quantity: 10PCS
Packaging Details: 1pcs/carton box
Payment Terms: Western Union, T/T
Supply Ability: 90000PCS/MONTH
Get Best Price Contact Now

Detail Information

Fiber Type: G.652D, G.657A Cable Material: PVC, LSZH
Tube: Bare Fiber, 0.9mm, 2.0mm, 3.0mm Connector Type: SC/UPC, SC/APC, FC/UPC, FC/APC, LC/UPC, LC/APC
Port: 1*2, 2*2, 1*4, 2*4, 1*8, 2*8, 1*16, 2*16, 1*32, 2*32, 1*64, 2*64 Pigtail Length: 0.5M, 1.0M, 1.5M
High Light:

plc optical splitter

,

passive optical splitter

Product Description

Fiber Planar Lightwave Circuit Fiber Optic Splitter ABS Module Low PDL 1 × 32



PLC Splitter
Planar lightwave circuit splitter (PLC Splitter) is a kind of integrated waveguide optical power distribution device based on quartz substrate. It has the advantages of small volume, wide bandwidth, high reliability, excellent uniformity. Optical fiber splitter is especially suitable for passive optical networks (EPON, BPON, GPON) which is connected with the terminal equipment and realize the optical power distribution.

FOC COMMUNICATION CO., LTD provides 1*N and 2*N fiber optic splitters. And these PLC splitters can be made as per customer request.



Features

Low PDL
Low Insertion loss

High Return Loss
Uniform Power Splitting
Compact Design
Wide Operating Wavelength



Applications

CATV Systems
Optical Signal Distribution
Test Equipments

FTTX (FTTP, FTTH, FTTN, FTTC)
Passive Optical Networks (PON)
Local Area Networks (LAN)


Optical Specifications

Parameter

Unit

Specification (P Grade)

Channel Number



1X2

1X4

1X8

1X16

1X32

1X64

Operation Wavelength

nm

1260~1650

Insertion Loss (Max.)

dB

4.3

7.4

10.7

13.9

17.2

21.5

Uniformity (Max.)

dB

0.5

0.8

1.0

1.4

1.6

2.0

Polarization Dependent Loss

dB

0.2

0.3

0.3

0.3

0.3

0.5

Return Loss

dB

≥50

Directivity

dB

≥50

Operating Temperature

-40~+85

Storage Temperature

-40~+85

Note: All the data above does not include connectors.

Ordering Information

PLC















Port

Fiber Type

Input

Output

Pigtail Length

Connector





PLC

0102=1x2
0104=1x4
0108=1x8
0116=1x16
0132=1x32
0164=1x64
0204=2x4
0208=2x8
0216=2x16
0232=2x32
0264=2x64

1=G652D, 2=G657A

L=900µm Loose tube, S=2.0mm, R=3.0mm, 0=Adapter

L=900µm Loose tube, S=2.0mm, R=3.0mm, 0=Adapter

05-20=0.5--2.0m, 0=Adapter, X=Others

FU=FC/UPC, FA=FC/APC, SU=SC/UPC, SA=SC/APC, ST=ST/UPC, LU=LC/UPC, LA=LC/APC, 00=None, X=Others


Fiber Planar Lightwave Circuit Fiber Optic Splitter ABS Module Low PDL 1 × 32 0
Fiber Planar Lightwave Circuit Fiber Optic Splitter ABS Module Low PDL 1 × 32 1



We can produce many serials of PLC splitters including:
1×2, 1×4, 1×8, 1×16, 1×32, 1×64, 2×4, 2×8, 2×16, 2×32, 2×64 with following package
Bare fiber series
Mini loose tube package
ABS Module type
LGX box type
Rack Mount patch panel for PON application.
Wall Mount patch panel for PON application
Inline fiber optic splice closure type
Erect fiber optic splice closure type
